Inovance MD500-PLUS Series User Manual

Function Application
‑551‑
3.3.2 DO Functions
Table 3–15 Parameters
Para.
Function
Default Value Range
Description
F5‑01
Extension
card relay
output
function
selection
0 0 to 42
See "
Table 3–16 DO functions " on
page 552
.
F5‑02
Control board
relay function
selection (T/
A1‑T/B1‑TC1)
2
F5‑03
Control board
relay function
selection (T/
A2‑TC2)
0
F5‑04
DO1 function
selection
0
F5‑05
Extension
card DO2
output
selection
4
F5‑17
Extension
card relay
output delay
0.0s 0.0s to
3600.0s
Indicates the output delay of relay on
the extension card. F5‑01 outputs the
active signal only after the set delay
time expires.
F5‑18
Relay 1 output
delay
0.0s 0.0s to
3600.0s
Indicates the delay of relay 1 on the
control board. F5‑02 outputs the
active signal only after the set delay
time expires.
F5‑19
Relay 2 output
delay
0.0 0.0 to 3600.0
Indicates the delay of relay 2 on the
control board. F5‑03 outputs the
active signal only after the set delay
time expires.
F5‑20 DO1 output
delay
0.0s 0.0s to
3600.0s
Indicates the delay of DO1 output. F5‑
04 outputs the active signal only after
the set delay time expires.
F5‑21 Extension
card DO2
output delay
0.0s 0.0s to
3600.0s
Indicates the delay of DO2 output on
the extension card. F5‑05 outputs the
active signal only after the set delay
time expires.
