Intel® Server Board S2600CW Family TPS
Intel® Server Board S2600CW Connector/Header Locations and Pin-outs
Revision 2.4
109
A51
GND
GND
B51
I
PETN8
A52
O
PERP8
B52
GND
GND
A53
O
PERN8
B53
GND
GND
A54
GND
GND
B54
I
PETP9
A55
GND
GND
B55
I
PETN9
A56
O
PERP9
B56
GND
GND
A57
O
PERN9
B57
GND
GND
A58
GND
GND
B58
I
PETP10
A59
GND
GND
B59
I
PETN10
A60
O
PERP10
B60
GND
GND
A61
O
PERN10
B61
GND
GND
A62
GND
GND
B62
I
PETP11
A63
GND
GND
B63
I
PETN11
A64
O
PERP11
B64
GND
GND
A65
O
PERN11
B65
GND
GND
A66
GND
GND
B66
I
PETP12
A67
GND
GND
B67
I
PETN12
A68
O
PERP12
B68
GND
GND
A69
O
PERN12
B69
GND
GND
A70
GND
GND
B70
I
PETP13
A71
GND
GND
B71
I
PETN13
A72
O
PERP13
B72
GND
GND
A73
O
PERN13
B73
GND
GND
A74
GND
GND
B74
I
PETP14
A75
GND
GND
B75
I
PETN14
A76
O
PERP14
B76
GND
GND
A77
O
PERN14
B77
GND
GND
A78
GND
GND
B78
I
PETP15
A79
GND
GND
B79
I
PETN15
A80
O
PERP15
B80
GND
GND
A81
O
PERN15
B81
I
NC (PRSNT2_N)
A82
GND
GND
B82
I
NC (RSVD)
PCIe riser slot reuses the same mechanical slot as the standard PCIe x16 slot and only
redefines several RSVD, PRSNT and JTAG pins for dedicated riser usage. Standard PCIe X16
card is also supported in the riser slot.
A summary of all changes made on the PCIe x16 riser slot compared with industry PCIe Spec:
• Reuse Pin B3 as the P12V Power.
• Reuse Pin A5/A8/A19/B30 as P3V3 Power.
