Appendix C: BMC Sensor Tables Intel® Server Board S2600CW Family TPS
158
Revision 2.4
Full Sensor Name
(Sensor name in SDR)
Senso
r #
Platform
Applicabili
ty
Sensor Type Event/Rea
ding Type
Event Offset
Triggers
Contrib. To
System
Status
Assert
/De-
assert
Readab
le
Value/
Offsets
Event
Data
Rearm Stand-
by
06 – Non-Redundant:
degraded from fully
redundant.
Degraded
07 - Redundant
degraded from non-
redundant
Degraded
SSB Thermal Trip
(SSB Therm Trip)
0Dh All
Temperature
01h
Digital
Discrete
03h
01 – State Asserted Fatal
As
and
De
– Trig Offset M X
IO Module Presence
(IO Mod Presence)
0Eh
Platform-
specific
Module/Board
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As
and
De
– Trig Offset M -
SAS Module Presence
(SAS Mod Presence)
0Fh
Platform-
specific
Module/Board
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As
and
De
– Trig Offset M X
BMC Firmware Health
(BMC FW Health)
10h All
Mgmt Health
28h
Sensor
Specific
6Fh
04 – Sensor Failure
Degraded
As - Trig Offset A X
System Airflow
(System Airflow)
11h All
Other Units
0Bh
Threshold
01h
– – – Analog – – –
FW Update Status 12h All
Version Change
2Bh
OEM
defined
70h
00h – Update started
01h – Update
completed
successfully.
02h – Update failure
OK As _ Trig Offset A _
IO Module2 Presence
(IO Mod2 Presence)
13h
Platform-
specific
Module/Board
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As
and
De
– Trig Offset M -
