Intel Stratix 10 Configuration User Guide

Manufacturer Product Family Data Width Density (Megabit) Device Name
(16)
GL-S 16 128 S29GL128S
256 S29GL256S
512 S29GL512S
1024 S29GL01GS
Macronix MX29LV 16 16 MX29LV160D
32 MX29LV320D
64 MX29LV640D
MX29LV640E
MX29GL 16 128 MX29GL128E
256 MX29GL256E
Eon Silicon Solution EN29LV 16 16 EN29LV160B
EN29GL 16 32 EN29LV320B
128 EN29GL128
(16)
The PFL II IP core supports top and bottom boot block of the flash memory devices. For Micron
flash memory devices, the PFL II IP core supports top, bottom, and symmetrical blocks of flash
memory devices.
(17)
Intel tested flash device.
(18)
Supports page mode.
1. Supported CFI Flash Memory Devices
UG-S10CONFIG | 2018.11.02
Send Feedback
Intel Stratix 10 Configuration User Guide
113
