1.1.2. Intel Download Cables Supporting Configuration in Intel Stratix 10
Devices
Intel provides the following cables to download your design to the Intel Stratix 10
device on the PCB. Download cables support prototyping activity by providing detailed
debug messages via Intel Quartus Prime Programmer. You must use Intel download
cables for advanced debugging using the Signal Tap logic analyzer the System
Console.
Table 2. Intel Stratix 10-Supported Download Cable Capabilities
Download Cable Protocol Support Intel Stratix 10
Device
Cable Connection to PCB
Intel FPGA Download Cable II
(formerly the USB-Blaster II)
JTAG, AS 10-pin female plug
3M Part number: 2510-6002UB
Intel FPGA Ethernet Cable (formerly
the EthernetBlaster II)
JTAG, AS 10-pin female plug
For more information about download cables refer to Intel FPGAs and Programmable
Devices / Download Cables. This web page includes links to the user guides for all the
cables listed in Table 2 on page 8.
1.2. Intel Stratix 10 Configuration Architecture
The Secure Device Manager (SDM) is a triple-redundant processor-based module that
manages configuration and the security features of Intel Stratix 10 devices. The SDM
is available on all Intel Stratix 10 FPGAs and SoC devices.
The block diagram below provides an overview of the Intel Stratix 10 configuration
architecture which includes the following blocks:
• Secure device manager (SDM): More information about SDM is contained in later
sections.
• Configuration network: The SDM uses this dedicated, parallel configuration
network to distribute the configuration bitstream to Local Sector Managers (LSMs).
You cannot access this network.
• LSMs: The LSM is a microprocessor. Each configuration sector includes an LSM.
The LSM parses configuration bitstream and configures the logic elements for its
sector. After configuration, the microprocessors perform the following functions:
— Monitors for single event upsets at the sector level
— Processes responses to SEUs
— Performs hashing or integrity checks in real time
• Specific blocks for Intel Stratix 10 variants:
— SX devices include the hard processor system (HPS) in addition to FPGA logic.
— MX devices include a High Bandwidth Memory (HBM) in addition to FPGA logic.
— GX devices include FPGA logic and L- and H-Tile transceivers.
TX devices include FPGA logic and E- and H-Tile transceivers.
