Intel Stratix 10 Configuration User Guide

2.4. Intel Stratix 10 Configuration Pins
Intel Stratix 10 uses SDM pins for device configuration.
2.4.1. SDM Pin Mapping
You can use SDM pins for configuration and other functions; for example, power
management. You specify SDM I/O pin functions using the Device ➤ Configuration
➤ Device and Pin Options dialog box in the Intel Quartus Prime software. Refer to
the Intel Stratix 10 Device Pinouts and Intel Stratix 10 Pin Connection Guidelines for
more details on other functions.
Table 3. SDM Pin Mapping
SDM Pins MSEL
Function
Configuration Source Function Select Other
Functions
Avalon-ST x8 AS SD/MMC
SDM_IO0
— — — —
INIT_DONE
PWRMGT_SCL
PWRMGT_ALERT
DIRECT_TO_FAC
TORY
SEU_ERROR
SDM_IO1
—
AVSTx8_DATA2 AS_DATA1 SDMMC_CFG_DATA1
—
SDM_IO2
—
AVSTx8_DATA0 AS_CLK SDMMC_CFG_DATA0
—
SDM_IO3
—
AVSTx8_DATA3 AS_DATA2 SDMMC_CFG_DATA2
—
SDM_IO4
—
AVSTx8_DATA1 AS_DATA0 SDMMC_CFG_CMD
—
SDM_IO5 MSEL0
—
AS_nCSO0 SDMMC_CFG_CCLK CONF_DONE,
INIT_DONE
SDM_IO6
—
AVSTx8_DATA4 AS_DATA3 SDMMC_CFG_DATA3
—
SDM_IO7 MSEL1
—
AS_nCSO2
— —
SDM_IO8
—
AVST_READY
(1)
AS_nCSO3 SDMMC_CFG_DATA4
—
SDM_IO9 MSEL2
—
AS_nCSO1
— —
SDM_IO10
—
AVSTx8_DATA7
—
SDMMC_CFG_DATA7 DIRECT_TO_FAC
TORY
SEU_ERROR
SDM_IO11
—
AVSTx8_VALID
— —
PWRMGT_SDA
DIRECT_TO_FAC
TORY
SEU_ERROR
SDM_IO12
— — — —
PWRMGT_SDA
PEWRMGT_ALERT
DIRECT_TO_FAC
TORY
continued...
(1)
AVST_READY is applicable in Avalon-ST x8, x16 and x32 configuration schemes.
2. Intel Stratix 10 Configuration Details
UG-S10CONFIG | 2018.11.02
Send Feedback
Intel Stratix 10 Configuration User Guide
17
