Intel Stratix 10 Configuration User Guide

• Refer to Generating Remote System Upgrade Image Files using Programming
File Generator on page 84 for the step by step process to generate the
standard and single remote system upgrade image files using the
programming file generator.
3. The remote system update requires you to use the AS x4 configuration scheme to
configure the FPGA with the pre-generated remote system upgrade image.
4. Once the device enters user mode with either the factory image or an application
image, the remote system upgrade host can perform the following remote system
upgrade operations:
a. Reconfiguring the device with an application or factory image
i. From factory image to an application image or vice versa
ii. From an application image to another application image
b. Erasing the application image
c. Adding an application image
Related Information
• Intel Stratix 10 SoC Development Kit User Guide
• Mailbox Client Intel Stratix 10 FPGA IP Core User Guide
5.3. Commands and Error Codes
The remote system upgrade host communicates with the SDM using command and
response packets via the Mailbox Client Intel Stratix 10 FPGA IP.
Figure 40. Command and Error Code Header Format
31 30
RESERVED ID 0 I COMMAND / ERROR CODELENGTH
29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
The following table describes the fields of the header command.
Table 27. Mailbox Client Intel Stratix 10 FPGA IP Command and Error Code Header
Description
Header Bit Description
Reserved [31:28] Reserved.
ID
[27:24] The command ID. The response header returns the ID specified in the
command header. Set different IDs in each command to match responses
with commands.
0
[23] Reserved.
Length
[22:12] Number of words of arguments following the header.
I
[11]
Mailbox Client. Set this bit to 0 when sending commands using the
Mailbox Client Intel Stratix 10 FPGA IP core.
Command Code/Error
Code
[10:0]
Command Code specifies the command. The Error Code indicates
whether the command succeeded or failed.
5. Remote System Upgrade
UG-S10CONFIG | 2018.11.02
Intel Stratix 10 Configuration User Guide
Send Feedback
78
