Intel Stratix 10 Configuration User Guide

Figure 24. AS Configuration Serial Input Timing Diagram
nCSO
AS_CLK
AS_DATA IN0 IN1 INn
T
ext_delay
Note: For more information about the timing parameters, refer to the Intel Stratix 10 Device
Datasheet.
3.2.4. Programming Serial Flash Devices
You can program serial flash devices in-system using the Intel FPGA Download Cable
II or Intel FPGA Ethernet Cable.
3. Intel Stratix 10 Configuration Schemes
UG-S10CONFIG | 2018.11.02
Intel Stratix 10 Configuration User Guide
Send Feedback
54
