Intel Stratix 10 Configuration User Guide

• If you have multiple devices in the JTAG chain, try to disconnect other devices
from the JTAG chain to isolate the Intel Stratix 10 device.
•
If you specify the OSC_CLK_1 as the clock source for configuration, ensure that
OSC_CLK_1 is running at the frequency you specify in the Intel Quartus Prime
software.
• For designs including the High Bandwidth Memory (HBM2) IP or any IP using
transceivers, you must provide a free running and stable reference clock to the
device before device configuration begins. All transceiver power supplies must be
at the required voltage before configuration begins.
3. Intel Stratix 10 Configuration Schemes
UG-S10CONFIG | 2018.11.02
Intel Stratix 10 Configuration User Guide
Send Feedback
68
