Intel Stratix 10 Configuration User Guide

Command Code
(Hex)
Number
of
Command
s
(13)
Number
of
Response
s
(13)
Description
• Bit [31:4]: Reserved.
•
Bit [3]: SEU_ERROR.
•
Bit [2]: CVP_DONE.
•
Bit [1]: INIT_DONE.
•
Bit [0]: CONF_DONE.
4 Error
location
Contains the error location. Returns 0 for no error.
5 Error
details
Contains the error details. Returns 0 for no error.
RSU_STATUS
5B 0 8 Reports the current remote system upgrade status. This command
returns the following responses:
Wor
d
Summa
ry
Description
0-1 Current
Flash offset of the currently running application
image.
2-3 Last
failing
Flash offset of the last failing application image. A
value of all 1s indicates no failing images. When there
are no failing images, the following words do not
contain meaningful data.
4 State Failure code of the last failing image.
The error field has two parts:
• Upper 16 bits: Major error code.
• Lower 16 bits: Minor errors that does not contain
meaningful data.
The following major error codes are defined:
Major Error
Code
Description
0xF001 BITSTREAM_ERROR
0xF002 HARDWARE_ACCESS_FAILURE
0xF003 BITSTREAM_CORRUPTION
0xF004 INTERNAL_ERROR
0xF005 DEVICE_ERROR
0xF006 HPS_WATCHDOG_TIMEOUT
0xF007 INTERNAL_UNKNOWN_ERROR
5 Version Contains the value of each of the soft functions,
whether that function is on an SDM pin.
6 Error
location
Contains the error location of the last failing image.
Returns 0 for no error.
7 Error
details
Contains the error details of the last failing image.
Returns 0 for no error.
QSPI_OPEN
32 0 0 Clients use this command to request exclusive access AS x4 interface.
The SDM returns the appropriate response:
continued...
(13)
The number does not include the command and response header.
5. Remote System Upgrade
UG-S10CONFIG | 2018.11.02
Intel Stratix 10 Configuration User Guide
Send Feedback
80
