Intermec EasyCoder PX6i Service Manual

viii EasyCoder PX4i and PX6i Service Manual
Before You Begin
Global Services and Support
Warranty Information
To understand the warranty for your Intermec product, visit the Intermec
web site at
http://www.intermec.com and click Service & Support. The
Intermec Global Sales & Service page appears. From the Service & Support
menu, move your pointer over Support, and then click Warranty.
Web Support
Visit the Intermec web site at http://www.intermec.com to download
our current documents in PDF format. To order printed versions of the
Intermec manuals, contact your local Intermec representative or distribu-
tor.
Visit the Intermec technical knowledge base (Knowledge Central) at
http://intermec.custhelp.com to review technical information or to request
technical support for your Intermec product.
Telephone Support
Contact your local Intermec representative. To search for your local repre-
sentative, from the Intermec web site, click Contact.
Who Should Read This Document?
This Service Manual provides you with in-depth information about the
EasyCoder PX4i and PX6i printers and how to maintain, repair, and trou-
bleshoot them. It is primarily intended for authorized service technicians.
Related Documents
The Intermec web site at http://www.intermec.com contains our current
documents that you can download in PDF format. To order printed ver-
sions of the Intermec manuals, contact your local Intermec representative
or distributor.
We recommend that the service technician keeps the following manuals
easily accessible in electronic or printed form:
• Intermec EasyCoder PX4i, User’s Guide (Fingerprint version)
• Intermec EasyCoder PX6i, User’s Guide (Fingerprint version)
• Intermec EasyCoder PX4i, User’s Guide (IPL version)
• Intermec EasyCoder PX6i, User’s Guide (IPL version)
• Intermec EasyCoder PX4i and PX6i, Spare Parts Catalog
• Installation Instructions for various options
• Intermec Direct Protocol v8.30 (or later), Programmer’s Reference Manual
• Intermec Fingerprint v8.00 (or later), Tutorial
• Intermec Fingerprint v8.30 (or later), Programmer’s Reference Manual
• IPL Programming, Reference Manual (rev. 007 or later)
• EasyLAN Interface Kit, Installation Instructions
• EasyLAN Wireless Interface Kit, Installation Instructions
• EasyLAN, User’s Guide
• EasyLAN Network Setup, User’s Guide

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
