EasyCoder PX4i and PX6i Service Manual 203
Chapter 16 — Interfaces
16.10 EasyLAN Wireless Interface Board
Description
This section describes how to install an EasyLAN Wireless network inter-
face in an EasyCoder PX4i and PX6i printer and how to connect it to a
LAN, WAN, Intranet, or Internet network via a wireless connection.
The installation instructions describes how to physically install the inter-
face board in a printer. Confi guration and setup are described in the
EasyLAN Wireless Kit, Installation Instructions and the Intermec EasyLAN,
User’s Guide on the attached CD-ROM.
This interface kit must only be physically installed by an authorized
service technician. The device is country/region specifi c and must be
ordered for the correct country/region. Use of this device in other region
than shown on the device home page/test label may violate applicable
law.
Printer Firmware
The printer must either be fi tted with Intermec Fingerprint v8.30 (or
later) or IPL v2.30 (or later). In Intermec Fingerprint, the network port is
addressed as device "net1:" (communication channel #5).
Installation Kit
The EasyLAN Interface Kit contains:
• One EasyLAN adapter board complete with radio module fi tted
• Rear plate (for EasyCoder PF2/4i-series printers only)
• RJ-45 plug (for EasyCoder PM4i, PX4i, and PX6i only)
• One light guide
• One hexagonal threaded spacer
• One antenna extension cable
• One antenna
• One cable clip
• One cable tie
• One CD-ROM with software and manuals
• One Installation Instruction booklet
The only tools required for the installation are #T10 and #T20 Torx screw-
drivers and a small wrench.

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
