68 EasyCoder PX4i and PX6i Service Manual
Chapter 8 — Print Unit
Pulley
Platen roller
Belt to platen roller
#T20 Torx screw
EasyCoder PX4i
In the illustration below, the upper parts of the print unit and the label
stop sensor have been removed to improve visibility.
#T20 Torx
screw
Stepper motor
Ball bearing
Plastic bearing
Spacer
Plastic bearing
Ball bearing
Bracket
#T20 Torx screw
Belt to ribbon
rewind unit
Spacer
