EasyCoder PX4i and PX6i Service Manual 41

Chapter 5 — Media Supply

Media roll

retainer

5.4 Media Roll Retainer

An optional media roll retainer can be pressed on the hub package (but

not on the adapter) of an EasyCoder PX4i in order to hold large media

rolls and to prevent the media from getting misaligned on the roll. The

retainer is not intended for EasyCoder PX6i
