110 EasyCoder PX4i and PX6i Service Manual

Chapter 9 — Liner Takeup Kit

EasyCoder PX6i

Tension roller

Belt to liner takeup unit

Belt to

liner drive roller

Stepper motor

Motor support plate

Brace

Break shaft

Liner takeup unit
