Printing
Print Technique Direct Thermal and Thermal Transfer
Printhead Resolution 8 dots/mm (203.2 dpi) or
11.81 dots/mm (300 dpi) Not supported by IPL
Print Speed (variable)
100 to 225 mm/sec. (≈ 4 to 8.85 in./sec.)
Print Width (max) 167.4 mm (6.59 in.)
Print Length (max) 32767 dots
= 409.5 cm (161.25 in.) at 203.2 dpi
1
= 277.5 cm (109.23 in.) at 300 dpi
1
Media Width (min/max) 76 to 170 mm (3 to 6.69 in.)
Media Roll Diameter (max) 213 mm (8.38 in.)
205 mm (8.07 in.)
Tear-off & Cut-off
Peel-off & batch takeup
Media Roll Core Diameter 38 to 40 mm (1.5 in.) or
76 mm (3 in.) with adapter fi tted
Ribbon Width (min/max)
76.2 to 170 mm (3 to 6.69 in.)
Ribbon Roll Diameter (outer), max. 80 mm (3.15 in.)
≈ 450 m (1476 ft) length
Ribbon Roll Core Diameter (inner) 25 mm (1.00 in.)
Print Directions 4
Modes of Operation
Tear-Off (Straight-through) Yes
Cut-Off Option With cutter
Peel-Off (Self-strip) Option With rewinder
Fingerprint Firmware
Operating System Intermec Fingerprint v8.30 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Resident Scaleable Fonts 15 Unicode fonts
2
Resident Bar Codes 59
Startup Program (std) Intermec Shell v8.2
IPL Firmware
Operating System IPL v2.30
Smooth Fonts 13 scaleable + 21 simulated bitmap
Resident Bar Codes 44
Physical Measures
Dimensions (W × L × H) 335 × 482 × 238 mm
(13.2 × 19.0 × 9.4 in)
Weight (excluding media) 14.8 kg (32.6 pounds)
Ambient Operating Temperature +5°C to +40°C (+41°F to +104°F)
Storage Temperature -20°C to +70°C (-4°F to +152°F)
Humidity 10 to 90% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 2 sockets for 4MB or 8MB each Std. 1 x 4MB
On-board SDRAM SIMM 1 socket for 16MB (Std. 16MB)
10 EasyCoder PX4i and PX6i Service Manual
Chapter 1 — Models and Options
1.3 EasyCoder PX6i Specifications
