Intermec EasyCoder PX6i Service Manual

Power Supply
AC Voltage 90 to 265 VAC, 45 to 65 Hz
PFC Regulation IEC 61000-3-2
Power Consumption Standby 20W; Continuous, average 175W;
Peak 400W
Sensors
Label Gap/Black Mark/Out of Media Yes Variable position
Printhead Lifted Yes
Ribbon End/Ribbon Low Yes
Paper Sensor Yes
Controls
Indicator Lamps 3
Display 2 x 16 character LCD Background light
Keyboard (Fingerprint) 22 keys membrane-switch type
Keyboard (IPL) 7 keys membrane-switch type
Print (FP) or Feed/Pause (IPL) button 1
Beeper Yes
Data Interfaces
Serial 1 x RS-232 + 1 x USB
Bar Code Wand Yes Not supported by IPL
Connection for Optional Interface Boards 1 EasyLAN + 2 other (Fingerprint/DP)
IPL: 1 other + 1 EasyLAN
Cutter Interface 1
Memory Card Adapter 1, for CompactFlash cards IPL: Not as memory
Accessories and Options
Integral Self-strip Unit with Liner Takeup Option
3,4
For peel-off operation
Fan-fold Guide Option
5
Cutter Option
5
Label Taken Sensor Option
3,4
Real Time Clock Option
3,4
Not supported by IPL
RS-232 Cable Option
Parallel Interface Cable Option
Parallel Interface Board Option
Double Serial Interface Board Option
3,4
Not supported by IPL
Serial/Industrial Interface Board Option
3,4
Not supported by IPL
EasyLAN Ethernet Interface Option
3,4
EasyLAN Wireless Interface Option
3,4
Built-in Alphanumeric Keyboard Option
3,4
Not supported by IPL
External Keyboard Converter Option
5
CompactFlash Cards Option
5
8MB-1GB
CompactFlash Protection Plate Option
5
1
/. The max. print length is also restricted by the amount of free SDRAM memory.
2
/. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3
/. Factory installed option
4
/. Field-installable kit. Installation should be performed by a service technician.
5
/. Operator-installable option.
EasyCoder PX4i and PX6i Service Manual
11
Chapter 1 — Models and Options

Intermec EasyCoder PX6i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	170 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	335 mm
Weight	14800 g
