Goodrive300-01A-RT series integrated machine Wiring instruction
-13-
Category
Sign
Name
Terminal function
4. Error: ±1%, 25°C
Digital
input/output
S1-COM
Digital input 1
1. Internal impedance: 3.3kΩ
2. 1230V voltage input is acceptable
3. Max. input frequency: 1kHz
You can select internal power (NPN mode) or
external power (PNP mode) through J9. The
default is internal power (NPN mode).
S2-COM
Digital input 2
S3-COM
Digital input 3
PTC-COM
Motor
overtemperature
protection
External PTC temperature switch signal input,
PTC resistance acts at 2.5kΩ.
Y1-COM
Digital reference
ground
1. Switch capacity: 50mA/30V
2. Output frequency range: 01kHz
3. Select whether Y1 output is low electrical
level or OC output through the jumper J3. OC
output is by default.
Communication
485+
RS485 communication
RS485 communication terminal, adopting the
Modbus protocol.
You can select the matching terminal resistor
through J2.
485-
Relay output
RO1A
NO contact of relay 1
1. Contact capacity: 3A/AC250V, 1A/DC30V.
2. Cannot be used as high-frequency switch
output.
RO1C
Common contact of
relay 1
Solenoid valve
TA1
Solenoid valve coil A
AC 220V/15W output terminals, connected to
solenoid valve coils.
TC1
Solenoid valve coil C
Jumper
terminal
J9
Internal/external
power selection
terminal
You can select internal power (NPN mode) or
external power (PNP mode) through J9. The
default is internal power (NPN mode).
J3
Digital output CME
selection terminal
Select whether Y1 output is low electrical
level or OC output through the jumper J3. OC
output is by default.
J10
COM/GND terminal
Short connection is by default.
J1
P1- analog signal
selection terminal
I corresponds to current signal, V
corresponds to voltage signal, and the default
is current input signal.
J7
+24V power output
terminal
You can select +24V output or 24V and 1.1Ω
resistor series connection output through the
jumper J7. By default, +24V output is selected
in factory.
