Goodrive300-01A-RT series integrated machine Function description
-38-
Function
code
Name
Description
Default
Modify
P03.14
Setting source of
forward rotation
upper-limit frequency
in torque control
0: Keypad (P03.16)
1: P1- (100% corresponding to the max.
frequency)
2–5: Reserved
6: Modbus communication (same as the
above)
7–9: Reserved
0
○
P03.15
Setting source of
reverse rotation
upper-limit frequency
in torque control
0: Keypad (P03.17)
1: P1- (100% corresponding to the max.
frequency)
2–5: Reserved
6: Modbus communication (same as the
above)
7–9: Reserved
0
○
P03.16
Forward rotation
upper-limit frequency
set through keypad in
torque control
0.00Hz–P00.03
50.00Hz
○
P03.17
Reverse rotation
upper-limit frequency
set through keypad in
torque control
0.00 Hz–P00.03
50.00Hz
○
P03.18
Setting source of
electromotive torque
upper limit
0: Keypad (P03.20)
1: P1- (100% corresponding to three times
the motor rated current)
2–4: Reserved
5: Modbus communication (same as the
above)
6–8: Reserved
0
○
P03.19
Setting source of
braking torque upper
limit
0: Keypad (P03.21)
1: P1- (100% corresponding to three times
the motor rated current)
2–4: Reserved
5: Modbus communication (same as the
above)
6–8: Reserved
0
○
