INVT Goodrive300-01A-RT Series User Manual

Goodrive300-01A-RT series integrated machine Function description
-37-
Function
code
Name
Description
Default
Modify
P03.02
Low-point frequency
for switching
0.00Hz–P03.05
5.00Hz
○
P03.03
Speed-loop
proportional gain 2
0–200.0
10.0
○
P03.04
Speed-loop integral
time 2
0.000–10.000s
1.000s
○
P03.05
High-point frequency
for switching
P03.02–P00.03 (max. output frequency)
10.00Hz
○
P03.06
Speed-loop output filter
0–8 (corresponding to 0–2
8
/10ms)
0
○
P03.07
Electromotive slip
compensation
coefficient of vector
control
50%–200%
100%
○
P03.08
Power generation slip
compensation
coefficient of vector
control
50%–200%
100%
○
P03.09
ACR proportional
coefficient P
0–65535
Refer to the commissioning empirical
parameters:
P03.09
value
(reference)
P03.10 value
(reference)
Motor
power
2000
1000
7.5–22kW
2500
1500
30–37kW
1000
○
P03.10
ACR integral
coefficient I
1000
○
P03.11
Torque setting method
0: Torque control is invalid
1: Keypad (P03.12)
2: P1- (100% corresponding to three times
the motor rated current)
3–6: Reserved
7: Modbus communication (same as the
above)
8–10: Reserved
0
○
P03.12
Torque set through
keypad
-300.0%–300.0% (of the motor rated current)
50.0%
○
P03.13
Torque reference filter
time
0.000–10.000s
0.010s
○
