Johnson Controls York YCIV A Series User Manual

JOHNSON CONTROLS
125
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
6
DIMENSIONS - 2 AND 3 COMPRESSOR ENGLISH (CONT'D)
33 5/16"
103 3/8"
80"
230"
101 5/8" 50" 50 5/16"9 1/8"
93 15/16"
1 5/16" (TYP)
X
G
C
Y
(3) RIGGING HOLES
EACH SIDE (3 X 2)
10"
WATER OUTLET
10"
WATER INLET
VIEW D-D
X
G
C
Z
D
D
A
A
5/8" MOUNTING
HOLES (TYP)
ORIGIN
POWER: SINGLE POINT WITH TERMINAL BLOCK
CONTROL PANEL
45 5/16"
60"
14 1/8"
C
D
