Johnson Controls York YCIV A Series User Manual

JOHNSON CONTROLS
127
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
6
DIMENSIONS - 2 AND 3 COMPRESSOR ENGLISH (CONT'D)
POWER: SINGLE POINT WITH TERMINAL BLOCK
X
G
C
Y
VIEW D-D
B
33 5/16"
103 5/16"
A
112 13/16"
84 1/2"
93 15/16"
D
D
X
G
C
Z
10" (WATER INLET)
10" (WATER OUTLET)
A
A
9 1/8"
50 5/16"50"86 5/16"69 11/16"
1 5/16" (TYP)
5/8" MOUNTING
HOLES (TYP)
(3) RIGGING HOLES
EACH SIDE 3 X 2
CONTROL PANEL
45 5/16"
60"
14 1/8"
