Johnson Controls York YCIV A Series User Manual

JOHNSON CONTROLS
161
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
6
ISOLATOR CROSS REFERENCE
OLD PART NUMBER MASON
NEW PART NUM-
BER
THE VMC
029-24583-002 CIP-B-450 RED 029-25334-002 CP-1D-510 BLACK
029-24583-003 CIP-B-750 WHITE 029-25334-003 CP-1D-900 DK GREEN
029-24583-004 CIP-B-1000 BLUE 029-25334-004 CP-1D-1200 GRAY
029-24583-005 CIP-B-1250 GRAY 029-25334-005 CP-1D-1360 WHITE
029-24583-006 CIP-B-1650 BLACK 029-25334-006 CP-1 D-1785N GRAY IRED
029-24583-007 CIP-C-1000 BLACK
029-25334-008 C2P-1D-1350 DARK PURPLE
029-24583-008 CIP-C-1350 YELLOW
029-24583-009
CIP-C-1750 BLACK STRIPE WITH
RED
029-25334-009 C2P-1D-1800 DARK GREEN
029-24583-010 CIP-C-2100 YELLOW WITH RED
029-25334-010 C2P-1D-2400 GRAY
029-24583-011 CIP-C-2385 YELLOW WITH GREEN
029-24583-012 CIP-C-2650 RED WITH RED 029-25334-012 C2P-1D-2720 WHITE
029-24583-013 CIP-C-2935 RED WITH GREEN 029-25334-013 C2P-1D-3570N GRAY/iRED
029-24584-001 ND-C YELLOW 029-25335-001 RD-3 CHARCOAL-WR
029-24584-002 ND-D YELLOW 029-25335-002 RD-4 BRICK RED-WR
029-24584-004 ND-DS YELLOW 029-25335-004 RD-4 CHARCOAL-WR
029-24585-006 SLRS-2-C2-420 RED
029-25336-006 Y2RSI-2D-460 GREEN
029-24585-007 SLRS-2-C2-520 WHITE
029-24585-008 SLRS-2-C2-660 BLACK 029-25336-008 Y2RSI-2D-710 DK BROWN
029-24585-009 SLRS-2-C2-920 BLUE 029-25336-009 Y2RSI-2D-870 RED
029-24585-010 SLRS-2-C2-1220 GREEN 029-25336-010 Y2RSI-2D-1200N RED/BLACK
029-24585-011 SLRS-2-C2-1760 GRAY 029-25336-011 Y2RSI-2D-1690 PINK
029-24585-012 SLRS-2-C2-2420 SILVER 029-25336-012 Y2RSI-2D-2640N PINK/GRAY
029-24585-013 SLRS-2-C2-3080 GRAY WITH RED 029-25336-013
Y2RSI-2D-2870N PINK/GRAY/OR-
ANGE
029-24585-014
SLRS-2-C2-3740 SILVER WITH
RED
029-25336-014 Y2RSI-2D-3600 PINK/GRAY/BROWN
