COMPLETE PIN NUMBER DESCRIPTION (CONT'D)
FEATURE DESCRIPTION OPTION DESCRIPTION
BAS BAS Interface (PIN 21)
X No BAS Reset/Offset required
T BAS/EMS Temp Reset/Offset
C BAS/EMS Current Reset/Offset
B BAS/EMS Both Temp and Current Reset/Offset
M ISN Microgateway
Q Special BAS Reset/Offset required
LCD LCD (PIN 22)
X English LCD & Keypad Display (std)
S Spanish LCD & Keypad Display
F French LCD & Keypad Display
G German LCD & Keypad Display
I Italian LCD & Keypad Display
P Portuguese LCD & Keypad Display
Q Special LCD & Keypad Display
RDOUT Silent Night (PIN 23)
X No option required
N Silent Night sound limiting control option
Q Special quote
SAFETY Safety Code (PIN 24)
L N. American Safety Code (cUL/cETL)
C CE listing
Q Special Safety Code
SENSOR PIN 25
X No option required
Q Special quote
PUMP Pump Control (PIN 26)
X No Pump Control required
Q Special Pump Control required
REMOTE Remote Ctrl Panel (PIN 27)
X No Remote Control Panel required
O OptiView Remote Control Panel required
Q Special Remote Control Panel required
SEQ Sequence Kit (PIN 28)
X No Sequence Kit required
S Sequence Control & Automatic Lead Transfer = {seq}
Q Special Sequence Kit required
TEMP Water Temp (PIN 29, 30)
NUM Leaving Water Temp. = {temp} degrees
QQ Special LWT requirements
CHICAGO Chicago Code Kit (PIN 31)
X No Chicago Code Kit required
C Chicago Code Kit required
S Service Isolation Valve
B Both Isolation Valve and Chicago Code
P Pressure Relief Service Valve Kit
D Service Isolation & Pressure Relief Valve Kit
R Dual Pressure Relief
G Dual Pressure Relief & Suction Service Isolation
Q Special Chicago Code Kit required
VALVES Valves (PIN 32)
X Standard Valves required
Q Special Optional Valves required
HGBP PIN 33
X No option required
Q Special quote
GAUGE PIN 34
X No option required
Q Special quote
OVERLOAD PIN 35
X No option required
Q Special quote
PIN36 PIN 36
X No option required
Q Special quote
