JOHNSON CONTROLS
83
SECTION 6 - TECHNICAL DATA
FORM 201.23-NM2
ISSUE DATE: 3/9/2015
6
HIGH EFFICIENCY YCIV_ _ _ _ E/V HIGH EFFICIENCY YCIV_ _ _ _ E/V
MODEL NO./NAME-
PLATE
SYSTEM 1 SYSTEM 2
STD. & ULTRA QUIET
COND. FANS
HIGH HEAD/STATIC
COND. FANS
TWO-SPEED
COND. FANS
STD. & ULTRA QUIET COND. FANS HIGH HEAD/STATIC COND. FANS TWO-SPEED COND. FANS
YCIV
E/V
INPUT
VOLTS
(9)
INPUT
FREQ
COMPRESSOR
CONDENSER
FANS
COMPRESSOR
CONDENSER
FANS
COMPRESSOR
CONDENSER
FANS
COMPRESSOR
CONDENSER
FANS
COMPRESSOR
CONDENSER
FANS
COMPRESSOR
CONDENSER
FANS
RLA (5) QTY.
FLA
(EA)
RLA (5) QTY.
FLA
(EA)
RLA (5) QTY.
FLA
(EA)
RLA (5) QTY.
FLA
(EA)
RLA (5) QTY.
FLA
(EA)
RLA (5) QTY.
FLA
(EA)
0157
460 60 110 4 2.8 110 4 2.8
380 60 139 4 3.5 139 4 9.3 139 4 3.5 139 4 9.3
0177
460 60 111 5 2.8 122 4 2.8
380 60 141 5 3.5 141 5 9.3 154 4 3.5 154 4 9.3
0187
460 60 154 5 2.8 105 5 2.8
380 60 195 5 3.5 195 5 9.3 132 5 3.5 132 5 9.3
0197
460 60 141 5 2.8 141 5 2.8
380 60 179 5 3.5 179 5 9.3 179 5 3.5 179 5 9.3
0207
460 60 141 6 2.8 152 5 2.8
380 60 179 6 3.5 179 6 9.3 193 5 3.5 193 5 9.3
0227
460 60 150 6 2.8 150 6 2.8
380 60 190 6 3.5 190 6 9.3 190 6 3.5 190 6 9.3
0247
460 60 194 6 2.8 149 6 2.8
380 60 245 6 3.5 245 6 9.3 188 6 3.5 188 6 9.3
YCIV
E/V
CONTROL
KVA (7)
UNIT SHORT CIRCUIT WITH-
STAND (KA)
FIELD WIRING & PROTECTION FIELD WIRING & PROTECTION
STD. & ULTRA QUIET COND. FANS HIGH HEAD/HIGH STATIC FANS TWO-SPEED COND. FANS
TERMINAL
BLOCK (STD)
CIRCUIT
BREAKER
(OPT)
MINI-
MUM CKT.
AMPACITY
(MCA) (3)
RECOMMEND-
ED FUSE/CKT.
BREAKER RAT-
ING (4)
MAX. IN-
VERSE TIME
CKT. BRKR.
RATING (2)
MAX DUAL
ELEMENT
FUSE
SIZE (2)
MINIMUM
CKT.
AMPACITY
(MCA) (3)
RECOMMENDED
FUSE/CKT.
BREAKER RAT-
ING (4)
MAX.
INVERSE
TIME CKT.
BRKR. RAT-
ING (2)
MAX DUAL
ELEMENT
FUSE
SIZE (2)
MINIMUM
CKT.
AMPACITY
(MCA) (3)
RECOMMENDED
FUSE/CKT.
BREAKER RAT-
ING (4)
MAX.
INVERSE
TIME CKT.
BRKR.
RATING (2)
MAX DUAL
ELEMENT
FUSE
SIZE (2)
0157
1.8 30KA 65KA 270 300 350 350
1.8 30KA 65KA 341 400 450 450 388 450 500 500
0177
1.8 30KA 65KA 288 350 400 400
1.8 30KA 65KA 365 450 500 500 417 500 500 500
0187
1.8 30KA 65KA 325 400 450 450
1.8 30KA 65KA 411 500 600 600 469 600 600 600
0197
1.8 30KA 65KA 345 400 450 450
1.8 30KA 65KA 437 500 600 600 495 600 600 600
0207
1.8 30KA 65KA 362 450 500 500
1.8 30KA 65KA 458 600 600 600 522 600 700 700
0227
1.8 30KA 65KA 371 450 500 500
1.8 30KA 65KA 469 600 600 600 539 600 700 700
0247
1.8 30KA 65KA 424 500 600 600
1.8 30KA 65KA 536 700 700 700 606 700 800 800
See page 92 for Electrical Data footnotes.
HIGH EFFICIENCY 2-COMPRESSOR UNITS (CONT'D)
One Field Provided Power Supply Circuit. Field Connections to Factory provided
Terminal Block (Standard); or Individual System Breakers (Optional).
