FORM 201.23-NM2
ISSUE DATE: 3/9/2015
SECTION 6 - TECHNICAL DATA
HIGH EFFICIENCY 2-COMPRESSOR UNITS (CONT'D)
HIGH EFFICIENCY YCIV_ _ _ _ E/V
MODEL NO./NAMEPLATE
FIELD WIRING LUGS
STD TERMINAL
BLOCK STD.,
U.Q. & TWO-SPD
COND. FANS
OPT CIRCUIT
BREAKER STD.,
U.Q. & 2-SPD
COND. FANS
STD TERMINAL
BLOCK HIGH
HEAD/HIGH STAT-
IC COND. FANS
OPT CIRCUIT
BREAKER HIGH
HEAD/HIGH STAT-
IC COND. FANS
YCIV E/V
INPUT
VOLTS
(9)
INPUT
FREQ
LUGS/
PHASE
(1)
LUG
WIRE
RANGE
LUGS/
PHASE
(1)
LUG
WIRE
RANGE
LUGS/
PHASE
(1)
LUG
WIRE
RANGE
LUGS/
PHASE
(1)
LUG
WIRE
RANGE
0157
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
0177
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
0187
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
0197
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
0207
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
0227
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
0247
460 60 2
#2 - 600
KCM
2 #2/0 - 500 KCM
380 60 3
#2 - 600
KCM
3 #3/0 - 400 KCM 3
#2 - 600
KCM
3
#3/0 -
400 KCM
