4-20
(1) When selecting OWN SHIP
a) Tap .
b) Set a comment, a symbol, and a colour, and tap .
(2) When selecting MANUAL
a) Tap .
b) Set a comment, a symbol, and a colour, and tap .
(3) Selecting PLOT
a) Tap .
b) A plotting screen is displayed.
c) Move the cursor to the position you want to register by using the Up/Down/Left/Right
arrows.
d) Tap "SET".
e) The cursor position is registered.
f) Set a comment, a symbol, and a colour and tap .
Item Description
QUADRANT Select North latitude/South latitude/East latitude/West latitude
of the latitude/lon
itude.
NE North latitude/East latitude
NW North latitude/West latitude
SE South latitude/East latitude
SW South latitude/West latitude
LAT Enter a latitude.
LON Enter a longitude.
Cursor position
Bearing/distance from own ship to the cursor position
Registered waypoint
