To connect the router to a BITS external clocking device:
1. Attach an electrostatic discharge (ESD) grounding strap on your bare wrist, and connect the strap to
one of the ESD points on the chassis.
2. Plug one end of the RJ-45 cable into the internal clock port on the RCB.
3. Plug the other end of the RJ-45 cable into the BITS external clocking device.
4. Verify that the LEDs for the BITS port are lit steadily green.
5. Configure the port. See Configuring Clock Synchronization Interface on MX Series Routers.
Table 40: BITS Port on the RCB
DescriptionLabel
Callout
(see Figure 29 on page 101)
Building-Integrated Timing Supply (BITS) clock
interface port.
BITS9
SEE ALSO
MX10003 Routing and Control Board (RCB) Description | 47
Prevention of Electrostatic Discharge Damage | 182
Powering On and Off the MX10003
IN THIS SECTION
Powering On an AC-Powered MX10003 Router | 107
Powering On a DC-Powered MX10003 Router | 108
Powering Off the MX10003 Router | 110
106
