Juniper MX10003 Hardware Guide

Multi-Rate Ethernet MIC LEDs
For the Multi-Rate MICs supported by MX series routers, see Multi-Rate Ethernet MIC.
The Multi-Rate Ethernet Modular Interface Card (MIC) has link LEDs located on the front panel.
Table 20 on page 57 describes the link LEDs in more detail.
Table 20: Multi-Rate Ethernet MIC LEDs
DescriptionStateColor
Link is up.On
steadily
Green
No link.Off
Like port status LED, each individual lane LED support four states: OFF, AMBER, GREEN, RED. See MPC
and MIC Lane LED Scheme Overview for more details.
SEE ALSO
MPC and MIC Lane LED Scheme Overview
Configuring Rate Selectability on MX10003 MPC to Enable Different Port Speeds
MX10003 MPC Rate-Selectability Overview
Understanding Rate Selectability
MICs Supported by MX Series Routers
57

Juniper MX10003 Specifications

General

Model	MX10003
Category	Network Router
Routing Engine	RE-MX10003
Throughput	2.4 Tbps
Operating System	Junos OS
Power Supply	AC or DC
Rack Units/Form Factor	3 U
Redundancy	Power supplies, fans
Slot Count	3
