Juniper MX10003 Hardware Guide

Figure 11: AC Power Supplies Components
3—1— Status LEDEjector lever
4—2— HandleAC inlet plug
SEE ALSO
Routine Maintenance Procedures for MX10003 Routers | 116
MX10003 Router AC Power Specifications
Table 12 on page 37 lists the AC power system electrical specifications.
Table 12: AC Power System Electrical Specifications
SpecificationItem
Operating range:
AC low: 90 through 140 VAC
AC high: 180 through 264 VAC
AC input voltage
50 through 60 Hz (nominal)AC input line frequency
25 AAC system current rating
2500 WAC system input power
Table 13 on page 38 lists the AC power supply electrical specifications.
37

Juniper MX10003 Specifications

General

Model	MX10003
Category	Network Router
Routing Engine	RE-MX10003
Throughput	2.4 Tbps
Operating System	Junos OS
Power Supply	AC or DC
Rack Units/Form Factor	3 U
Redundancy	Power supplies, fans
Slot Count	3
