Removing an MX10003 Fan Module
NOTE: To prevent overheating, install the replacement fan module immediately after removing
the existing fan module.
To remove the fan module (see Figure 38 on page 124):
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the ESD points on
the chassis.
2. Loosen the captive screw on the fan module faceplate (use a number-2 Phillips screwdriver).
3. Hold and lift the latch located on the inside of the fan module to release it from the chassis.
WARNING: To avoid injury, keep tools and your fingers away from the fans as you
slide the fan module out of the chassis. The fans might still be spinning.
4. Place one hand under the fan module to support it, and pull the fan module completely out of the
chassis.
Figure 38: Removing the Fan Module
g009831
