Page #43 background imageLoading...
Page #43 background image
MX10003 Router DC Power Specifications
Table 15 on page 43 lists the DC power system electrical specifications.
Table 15: DC Power System Electrical Specifications
SpecificationItem
Operating range: –40 through –72 VDCDC input voltage
54 A @ –48 VDC (maximum)DC system input current
rating
2500 WDC system input power
Table 16 on page 43 lists the DC power supply electrical specifications.
Table 16: DC Power Supply Electrical Specifications
SpecificationItem
1100 WMaximum output power
Minimum: –40 VDC
Nominal: –48 VDC, –60 VDC
Operating range: –40 through –72 VDC
DC input voltage
32 A @ –48 VDCDC input current rating
SEE ALSO
Routine Maintenance Procedures for MX10003 Routers | 116
Replacing an MX10003 DC Power Supply | 130
MX10003 Power Planning | 70
General Safety Guidelines and Warnings | 177
General Electrical Safety Guidelines and Warnings | 206
Prevention of Electrostatic Discharge Damage | 182
43
