MX10003 Chassis Description | 25
MX10003 Router Rack Requirements
The router can be installed in a standard 19-in. rack. Many types of racks are acceptable, including four-post
(telco) racks and open-frame racks. Table 24 on page 66 summarizes rack requirements and specifications
for the router.
Table 24: Router Rack Requirements and Specifications
GuidelinesRack Requirement
Use a four-post rack. You can mount the router on any four-post rack that
provides bracket holes or hole patterns spaced at 1 U (1.75-in./4.44-cm)
increments and that meets the size and strength requirements specified in this
table.
A U is the standard rack unit defined in Cabinets, Racks, Panels, and Associated
Equipment (document number EIA-310–D) published by the Electronics
Components Industry Association (http://www.ecianow.org/).
Rack type and mounting bracket
hole spacing
66
