Table 23: Router Physical Specifications (continued)
HeightDepthWidthWeightDescription
5.21 in. (13.23 cm;
3 U)
30 in. (76.2 cm)
without the cable
management
brackets, air filter
unit, and handles for
fans and power
supplies
19 in. (48.26 cm)50 lb (22.68 kg)Chassis without any
FRUs
5.19 in. (13.18 cm)5.43 in. (13.79 cm)19 in. (48.26 cm)5.51 lb (2.5 kg)Air filter unit along with
cable management
brackets
1.65 in. (4.19 cm)22.37 in. (56.82 cm)16.5 in. (41.91 cm)30 lb (13.61 kg)MPC (model number:
JNP10003-LC2103;
without any MIC in MIC1
slot)
1.65 in. (4.19 cm)8.97 in (22.78 cm)7.77 in. (19.73 cm)3 lb (1.36 kg)MIC (model number:
JNP-MIC1)
1.66 in. (4.21 cm)22.12 in. (56.18 cm)7.98 in. (20.27 cm)7.5 lb (3.4 kg)Routing and Control
Board (RCB)
4.99 in. (12.67 cm)9.27 in. (23.54 cm)2.46 in. (6.25 cm)1.5 lb (0.68 kg)fan module
1.63 in. (4.14 cm)9.26 in. (23.52 cm)3.53 in. (8.67 cm)3.4 lb (1.54 kg)AC power supply
1.63 in. (4.14 cm)10.8 in. (27.43 cm)3.53 in. (8.67 cm)4.4 lb (1.99 kg)DC power supply
NOTE: For router maintenance and to accommodate power cable bend radius, allow at least
30 in. (76.2 cm) in front of the rack and 24 in. (61 cm) behind the router (see “MX10003 Router
Clearance Requirements for Airflow and Hardware Maintenance” on page 63).
