Figure 50: Installing a MIC
SEE ALSO
Routine Maintenance Procedures for MX10003 Routers | 116
Prevention of Electrostatic Discharge Damage | 182
Maintaining MPCs
Purpose
The router can have up to two MPCs mounted horizontally in the card cage at the front of the chassis.
For optimum router performance, verify the condition of the MPCs.
Action
On a regular basis:
•
Check the OK/FAIL LED on the MPC. If the MPC detects a failure, the MPC sends an alarm message to
the Routing Engine.
•
Issue the show chassis fpc CLI command to check the status of installed MPCs. As shown in the sample
output, the value Online in the column labeled State indicates that the MPC is functioning normally:
user@host> show chassis fpc
Temp CPU Utilization (%) CPU Utilization (%) Memory
Utilization (%)
Slot State (C) Total Interrupt 1min 5min 15min DRAM (MB)
Heap Buffer
0 Online 57 24 0 21 23 23 3136
12 11
1 Online 58 20 0 21 23 23 3136
12 11
146
