pic—Logical PIC on the MIC. The number of logical PICs varies depending on the type of MIC.
•
port—Port number.
SEE ALSO
Interface Naming Conventions for MX10003 MPC
MX10003 MPC (Multi-Rate) LEDs
The MX10003 MPC (Multi-Rate) has LEDs located on the front panel.
Table 19 on page 56 describes the link LEDs in more detail.
Table 19: MX10003 MPC (Multi-Rate) LEDs
DescriptionStateColor
LED
Status
MPC is functioning normally and the link is up.On
steadily
GreenOK/FAIL
MPC is plugged-in but not powered on.Off
MPC has failed.-Red
MPC is online.-GreenONLINE
For information on the lane LEDs (Lo, L1, L2, and L3), see MPC and MIC Lane LED Scheme Overview.
SEE ALSO
MPC and MIC Lane LED Scheme Overview
Configuring Rate Selectability on MX10003 MPC to Enable Different Port Speeds
MX10003 MPC Rate-Selectability Overview
Understanding Rate Selectability
MICs Supported by MX Series Routers
Interface Naming Conventions for MX10003 MPC
56
