Juniper MX10003 Hardware Guide

Front Panel Components
Table 8 on page 28 lists the components on the front panel of the MX10003 router.
Table 8: Front Panel Components in a Fully Configured MX10003 Router
Number of FRUsSlotsComponent
20 and 1RCB
20 and 1MPC
11 per MPC
NOTE: MIC installs in slot 1 of the MPC.
MIC (installed in MPC)
2-Cable management brackets
1-Air filter unit
Rear Panel Components
Table 9 on page 28 lists the components on the rear panel of the MX10003 router.
Table 9: Rear Panel Components in a Fully Configured MX10003 Router
Number of FRUsSlotsComponent
60 through 5Power supply module
40 through 3Fan module
MX10003 Cable Management Bracket Description
The cable management bracket (see Figure 5 on page 29) consists of dividers and installs on the front of
the chassis. The cable management bracket enables you to route the cables outside the router and away
from the RCBs, MICs, and MPCs.
28

Juniper MX10003 Specifications

General

Model	MX10003
Category	Network Router
Routing Engine	RE-MX10003
Throughput	2.4 Tbps
Operating System	Junos OS
Power Supply	AC or DC
Rack Units/Form Factor	3 U
Redundancy	Power supplies, fans
Slot Count	3
