SEE ALSO
Replacing an MX10003 DC Power Supply | 130
Replacing an MX10003 AC Power Supply | 127
Replacing the MX10003 Air Filter Unit | 117
Replacing an MX10003 Fan Module | 123
Replacing an MX10003 MIC | 141
Replacing an MX10003 MPC | 148
MX10003 Chassis
IN THIS SECTION
MX10003 Chassis Description | 25
MX10003 Front and Rear Panel Components | 27
MX10003 Cable Management Bracket Description | 28
Alarm LEDs on the MX10003 Front Panel | 29
MX10003 Chassis Description
The router chassis is a rigid sheet metal structure that houses all the other router components.
Figure 1 on page 26 shows the front of the fully configured chassis. The chassis measures 5.21 in. (13.23 cm)
high, 17.6 in. (44.7 cm) wide, and 30 in. (76.2 cm) deep. The chassis installs in standard 800-mm or 900-mm
deep open rack, 19-in. equipment racks, or telco open-frame racks. The total weight of a fully loaded
router: up to 157.4 lb (71.4 kg) for an AC-powered chassis, and up to 163.4 lb (74.1 kg) for a DC-powered
chassis. For more information, see “MX10003 Router Physical Specifications” on page 64.
25
