SEE ALSO
Routine Maintenance Procedures for MX10003 Routers | 116
Prevention of Electrostatic Discharge Damage | 182
Replace an SFP, SFP+, or QSFP+ Transceiver
IN THIS SECTION
Remove a Transceiver | 157
Install a Transceiver | 158
The transceivers for Juniper Networks devices are hot-removable and hot-insertable field-replaceable
units (FRUs). You can remove and replace them without powering off the device or disrupting the device
functions.
Figure 53: Small Form-Factor Pluggable (SFP) Transceiver
g001855
Connector
Locking pin
Remove a Transceiver
To remove a transceiver:
1. Have ready a replacement transceiver or a transceiver slot plug, an antistatic mat, and a rubber safety
cap for the transceiver.
2. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
3. Label the cables connected to the transceiver so that you can reconnect them correctly later.
157
