Keithley 2000 User Manual

:LSELect <name>
:ROUTe:SCAN:LSELect <name> Perform specified scan operation
Parameters <name> = INTernal Enable scan for internal scanner card
EXTernal Enable scan for external scanner card
NONE Disable all scan operations
Query :LSELect?: Query scan operation
Description This command is used to select and perform the desired scan operation.
When INTernal is selected, the Model 2000 scans the channels of the internal
switching card according to how the scan is configured (see :SCAN[:INTer-
nal]).
EXTernal is used to measure channels that are controlled by an external
switch system. When EXTernal is selected, the Model 2000 scans the exter-
nal scan list (see :SCAN:EXTernal).
When NONE is used, the Model 2000 disables all operations associated with
a scan.
5-36 SCPI Command Reference

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
