Operation Event Register:
Bits B0 through B3 —
Not used.
Bit B4, Measuring (Meas) — Set bit indicates that the instrument is per-
forming a measurement.
Bit B5, Triggering (Trig) — Set bit indicates that the instrument is in the De-
vice Action block of the Trigger Model.
Bits B6 through B9 — Not used.
Bit B10, Idle — Set bit indicates that the instruments in the idle state.
Bits B11 through B15 — Not used.
Trig
B14 - B12B15
B11 B10 B9 B8 B7
B6 B5
B4 B1
B0
(2 )
5
32
00/1
Bit
Position
Event
Decimal
Weighting
Value
Value : 1 = Operation Event Set
0 = Operation Event Cleared
Events : Idle = Idle state of the 2000
Trig = Triggering
Meas = Measuring
Meas
(2 )
4
16
0/1
Idle
(2 )
10
1024
0/1
B3
B2
Figure 5-6
Operation event
register

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
