The Model 2000 can be configured to accept device-dependent commands of the Fluke Mod-
els 8840A/8842A. The commands to control the Model 2000 with the 8840A/8842A language
are provided in Table D-2.
Since the architecture of the Model 2000 differs from that of the 8840A/8842A, some com-
mands are different or cannot be used. Commands such as range, calibration, factory defaults,
and self-test do not map one-for-one. Also note that the Model 2000 does not have the speed
characteristics of the Models 8840A/8842A. Other commands of the Model 2000 have been
added to the 8840A/8842A command set, such as frequency, temperature, and scanner channels.
Refer to the appropriate manual for further details.
CAUTION The 8840A/8842A language is intended to be used only over the IEEE-488
bus. Using front panel controls in conjunction with this language may cause
erratic operation. In this case, results cannot be guaranteed.
Table D-2
Models 8840A/8842A device-dependent command summary
Mode Command Description
Function F1
F2
F3
F4
F5
F6
F7
F8
VDC (default)
VA C
2-wire k Ω
4-wire k Ω
mA DC
mA AC
Freq
Temp
Range
R0
R1
R2
R3
R4
R5
R6
R7
R8
VDC VAC k Ω * mA DC mA AC Freq
Auto on Auto on Auto on Auto on Auto on —
1V 1V 1k
Ω 10mA 3A 1V
10V 10V 10k
Ω 10mA 3A 10V
100V 100V 100k
Ω 100mA 3A 100V
1000V 750V 1M
Ω 1A 1A 750V
1000V 750V 10M
Ω 3A 3A 750V
1000V 750V 100M
Ω 3A 3A 750V
Auto off Auto off Auto off Auto off Auto off —
100mV 750V 100
Ω 3A 3A 750V
*2-wire and 4-wire ohms
Reading rate S0
S1
S2
slow, 10 PLC
Medium, 1 PLC, 6 ½
-digit resolution (default)
Fast, 0.1 PLC, 5 ½
-digit resolution
D-6 Models 196/199 and 8840A/8842A Commands

Keithley 2000 Specifications

General

Digits	6.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	100 Ω to 100 MΩ
Connectivity	IEEE-488 (GPIB)
Display Type	VFD
