Keithley 2000 User Manual

The Model 2000 can be configured to accept device-dependent commands of the Keithley
Models 196/199. The commands to control the Model 2000 with the 196/199 language are pro-
vided in Table D-1.
Since the architecture of the Model 2000 differs from that of the 196/199, some commands
are different or cannot be used. Commands such as function (offset-compensated ohms, AC cur-
rent dB), range, analog and digital filter, rate, calibration, factory defaults, and self-test do not
map one-for-one. Also note that the Model 2000 does not have the speed characteristics of the
Models 196/199. Other commands of the Model 2000 have been added to the 196/199 command
set, such as frequency, temperature, and scanning. Refer to the appropriate manual for further
details.
CAUTION The 196/199 language is intended to be used only over the IEEE-488 bus.
Using front panel controls in conjunction with this language may cause
erratic operation. In this case, results cannot be guaranteed.
Table D-1
Models 196/199 device-dependent command summary
Mode Command Description
Execute X Execute other device-dependent commands.
Function F0
F1
F2
F3
F4
F5
F6
F7
F8
F9
DC volts
AC volts
2-wire ohms
DC current
AC current
ACV dB
Not valid
Frequency
Temperature
4-wire ohms
Range
R0
R1
R2
R3
R4
R5
R6
R7
DCV ACV DCA ACA Ohms* ACV dB Freq
Auto Auto Auto Auto Auto Auto —
1V 1V 100mA 1A 1k Ω
1V .1V
10V 10V 3A 3A 10k Ω
10V 1V
100V 100V 3A 3A 100k Ω
100V 10V
1000V 750V 3A 3A 1M Ω
750V 100V
1000V 750V 3A 3A 10M Ω
750V 750V
1000V 750V 3A 3A 100M Ω
750V —
1000V 750V 3A 3A 100M Ω
750V —
*2-wire and 4-wire ohms
Zero (Rel) Z0
Z1
Z2
Zero disabled
Zero enabled
Zero enabled using a zero value (V)
Filter P0
P1
P2
Filter disabled
Moving filter (count = 10)
Repeat filter (count = 10)
D-2 Models 196/199 and 8840A/8842A Commands
