Keithley 2002 User Manual

IEEE-488 Reference
3-109
PRINT #1, "output 16; temp:tran int" ' Select the internal transducer
PRINT #1, "output 16; func 'temp'" ' Select the TEMP function
:RTD commands
See paragraph 2.4.5 for detailed information on making temperature measurements.
:TYPE <name>
[:SENSe[1]]:TEMPerature:RTD:TYPE <name> Set RTD parameters
<name> = PT100 Selects default parameters for the PT100 type (ITS-90)
D100 Selects default parameters for the D100 type (ITS-90)
F100 Selects default parameters for the F100 type (ITS-90)
PT385 Selects default parameters for the PT385 type (ITS-68)
PT3916 Selects default parameters for the PT3916 type (ITS-68)
USER Selects user-defined parameters
SPRTD Selects SPRTD type
:TYPE? Query RTD type
This command is used to select the RTD standard and the other related factors. When one of the
parameters other than USER is selected, the instrument defaults to the following RTD factors:
RZero
Standard Type Alpha Beta Delta Ω at 0°C
ITS-90 PT100 0.003850 0.10863 1.49990 100Ω
ITS-90 D100 0.003920 0.10630 1.49710 100Ω
ITS-90 F100 0.003900 0.11000 1.49589 100Ω
IPTS-68 PT385 0.003850 0.11100 1.50700 100Ω
IPTS-68 PT3916 0.003916 0.11600 1.50594 100Ω
Changing Alpha (see :ALPHa), Beta (see :BETA), Delta (see :DELTa) or Ω at 0°C (see
:RZERo) automatically changes the Type to USER (:TYPE USER). Thus, once you program
the appropriate factors for your RTD, you can later recall that setup by using the :TYPE USER
command.
PRINT #1, "output 16; temp:rtd:type pt385; type?" ' Select standard
PRINT #1, "enter 16" ' Get response from 2002
:ALPHa <NRf>
[:SENSe[1]]:TEMPerature:RTD:ALPHa <NRf> Specify Alpha value
<NRf> = 0 to 0.01 Specify RTD Alpha value
:ALPHa? Query the Alpha value
This command is used to check and/or change the Alpha value. Keep in mind that changing the
current Alpha value changes the Type to USER (see :RTD:TYPE).
PRINT #1, "output 16; temp:rtd:alpha .0035; alph?" ' Specify alpha value
PRINT #1, "enter 16" ' Get response from 2002
Program fragment
3.18.18
Parameters
Query
Description
Program fragment
Parameters
Query
Description
Program fragment

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
