Keithley 2002 User Manual

IEEE-488 Reference
3-122
:ENABle <NRf>
:STATus:MEASurement:ENABle <NRf> Program Measurement Event Enable Register
:STATus:QUEStionable:ENABle <NRf> Program Questionable Event Enable Register
:STATus:OPERation:ENABle <NRf> Program Operation Event Enable Register
:STATus:OPERation:TRIGger:ENABle <NRf> Program Trigger Event Enable Register
:STATus:OPERation:ARM:ENABle <NRf> Program Arm Event Enable Register
:STATus:OPERation:ARM:SEQuence:ENABle <NRf> Program Sequence Event Enable Register
<NRf> = 0 Clear register <NRf> = 128 Set bit B7
1 Set bit B0 256 Set bit B8
2 Set bit B1 512 Set bit B9
4 Set bit B2 1024 Set bit B10
8 Set bit B3 2048 Set bit B11
16 Set bit B4 16384 Set bit B14
32 Set bit B5 65535 Set all bits
64 Set bit B6
:ENABle? Query enable register
These commands are used to set the contents of the event enable registers (see Figures 3-27
through 3-32). An :ENABle command is sent with the decimal equivalent of the binary value
that determines the desired state (0 or 1) of each bit in the appropriate register.
Each event enable register is used as a mask for events (see [:EVENt] for descriptions of events).
When a bit in an event enable register is cleared (0), the corresponding bit in the event register
is masked and thus, cannot set the corresponding summary bit of the next register set in the sta-
tus structure. Conversely, when a bit in an event enable register is set (1), the corresponding bit
in the event register is unmasked. When the unmasked bit in the event register sets, the summary
bit of the next register set in the status structure will set.
The decimal weighting of the bits for each event enable register are included in Figures 3-27
through 3-32. The sum of the decimal weights of the bits that you wish to set is sent as the
parameter (<NRf>) for the appropriate :ENABle command. For example, to set the BFL and
RAV bits of the Measurement Event Enable Register, send the following command:
:stat:meas:enab 544
where; BFL (bit B9) = Decimal = 512
RAV (bit B5) = Decimal = 32
<NRf> = = 544
PRINT #1, "output 16; :stat:oper:enab 514; enab?" ' Set B1 and B9 of Op Enable
Register and query
PRINT #1, "enter 16" ' Get response message from
2002
3.20.2
Parameters
Query
Description
Program fragment

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
