Keithley 2002 User Manual

Front Panel Operation
2-82
SCAN
CONFIG EXT SCANNER
Reset scanner; press ENTR to >
< continue.
ENTER CONFIG EXT SCANNER
Set CHAN COUNT to infinite; >
< Press ENTER to continue.
ENTER SELECT TRIG SOURCE
TRIGLINK EXTERNAL TIMER>
< GPIB MANUAL IMMEDIATE
XXXXX CONFIG EXT SCANNER
Set CHAN SPACing to XXXXX. >
< Press ENTER to continue.
ENTER CONFIG EXT SCANNER
Set SCAN LIST for 80 channels >
< Press ENTER to continue.
ENTER CONFIG EXT SCANNER
STEP scanner to first cahnnel >
< Press ENTER to continue.
ENTER
Entry for
external list ➔
SCAN
SCAN COUNT = 00010 INFO: SCAN COUNT
Use <,>,^,v,ENTER,EXIT, or INFO Number of scans
ENTER USE SCAN TIMER?
YES NO
YES INTERVL = 000000.000 INFO: TIMER
Use <,>,^,v, ENTER,EXIT, or INFO For TIMER source, the interval >
< (in seconds) between triggers.
ENTER
NO DATA NO MEMORY?
YES NO
YES XXXXX RDGS TO BUFFER (Use CONFIG-STORE to
Press ENTER to continue. change number of readings)
ENTER
NO Press ENTER to begin
XXXX scans of XX channels or >
< press EXIT to abort.
ENTER +000.0000 mVDC CHXX
storing reading #XXX of XXX
SCAN COMPLETE
Storage complete; press RECALL
SCAN COMPLETE
RECALL-DATA SCAN-AGAIN EXIT
RECALL-DATA +000.0000 mVDC INFO: RECALL BY RDG#
Rdg# +00000 Use <,>,^,v to change reading. >
< Use NEXTDISP to see statistics
EXIT SCAN COMPLETE
RECALL-DATA SCAN-AGAIN EXIT
SCAN-AGAIN Press ENTER to begin
XXXX scans of XX channels or >
< press EXIT to abort.
EXIT DISABLE EXT SCANNER
Set CHAN SPACING to MANUAL >
< Press ENTER to continue.
Entry for
internal list ➔
Figure 2-32
SCAN key menu structure
