Keithley 2002 User Manual

IEEE-488 Reference
3-46
SCPI Command Summary
Tables 3-4 through 3-16 summarize the commands for each SCPI subsystem.
General notes:
• Brackets ([ ]) are used to denote optional character sets. These optional characters do not have to be included in the pro-
gram message. Do not use brackets in the program message.
• Angle brackets (< >) are used to indicate parameter type. Do not use angle brackets in the program message.
• The Boolean parameter (<b>) is used to enable or disable an instrument operation. 1 or ON enables the operation and 0 or
OFF disables the operation.
• Upper case characters indicate the short-form version for each command word.
• Default Parameter — Listed parameters are both the *RST and :SYSTem:PRESet defaults, unless noted otherwise. Param-
eter notes are located at the end of each table.
• SCPI — A checkmark ( √ ) indicates that the command and its parameters are SCPI confirmed. An unmarked command
indicates that it is non-SCPI. SCPI confirmed commands that use one or more non-SCPI parameters are explained by notes.
Table 3-4
CALCulate command summary
Command Description
Default
parameter SCPI Ref.
:CALCulate[1]
:FORMat <name>
:FORMat?
:KMATh
:MA0Factor <NRf>
:MA0Factor
:MA1Factor <NRf>
:MA1Factor
:MA2Factor <NRf>
:MA2Factor
:PERCent <NRf>
:PERCent?
:STATe <b>
:STATe?
:DATA
[:LATest]?
:FRESh?
:IMMediate
Subsystem to control CALC 1:
Select math format (NONE, POLynomial, PERCent,
PDEViation).
Query math format.
Path to configure math calculations:
Set “a0” for POLynomial (-9.999999e20 to +9.999999e20).
Query “a0” factor.
Set “a1” for POLynomial (-9.999999e20 to +9.999999e20).
Query “a1” factor.
Set “a2” for POLynomial (-9.999e20 to +9.999e20).
Query “a2” factor.
Set PERCENT (-9.999999e35 to +9.999999e35).
Query PERCENT.
Enable or disable calculation.
Query state of math function.
Path to read math result of CALC1.
Return the last math of CALC1.
Return a new (fresh) math result of CALC1.
Recalculate input data.
PERCent
0
1
0
1
0
√
√
√
√
√
√
√
√
√
√
3.12.1
:CALCulate2
:FORMat <name>
:FORMat?
:STATe <b>
:STATe?
:IMMediate
:DATA?
Subsystem to control CALC 2:
Select math format: (MEAN, SDEViation, MAXimum,
MINimum, PKPK, or NONE).
Query math format.
Enable or disable calculation.
Query state of math function.
Recalculate raw input data in buffer.
Read math result of CALC 2.
NONE
0
√
√
√
√
√
√
√
3.12.2

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
