E
IEEE-488 Conformance Information
E-1
Information
The IEEE-488.2 standard requires specific information about how the Model 2002 implements the standard. Paragraph 4.9 of
the IEEE-488.2 standard (Std 488.2-1987) lists the documentation requirements. Table E-1 provides a summary of the require-
ments, and provides the information or references the manual for that information.
Table E-1
IEEE-488 documentation requirements
Requirement Description or reference
(1)
(2)
(3)
(4)
(5)
(a)
(b)
(c)
(d)
(e)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
IEEE-488 Interface Function Codes.
Behavior of 2002 when the address is set outside the
range 0-30.
Behavior of 2002 when valid address is entered.
Power-On Setup Conditions.
Message Exchange Options:
Input buffer size.
Queries that return more than one response message
unit.
Queries that generate a response when parsed.
Queries that generate a response when read.
Coupled commands.
Functional elements required for SCPI commands.
Buffer size limitations for block data.
Syntax restrictions.
Response syntax for every query command.
Device-to-device message transfer that does not follow
rules of the standard.
Block data response size.
Common Commands implemented by 2002.
Calibration query information.
Trigger macro for *DDT.
Macro information.
See Appendix B.
Cannot enter an invalid address.
Address changes and bus resets.
Determine by :SYSTem:POSetup (para. 3.21.2).
256 bytes.
None.
All queries (Common Commands and SCPI).
None.
See Table E-2.
Contained in SCPI command subsystems tables (see Tables
3-4 through 3-16).
Block display messages: Top display = 20 characters max,
bottom display = 32 characters max.
See paragraphs 3.10 through 3.24.
See paragraphs 3.10 through 3.24.
None.
See paragraph 3.13.
See paragraph 3.10.
See Calibration Manual.
Not applicable.
Not applicable.
