Keithley 2002 User Manual

IEEE-488 Reference
3-49
Table 3-7
INPut command summary
Command Description
Default
parameter SCPI
:INPut
:PREamp
:STATe <b>
:STATe?
:FILTer <name>
:FILTer?
Path to control the Model 1801 Preamp:
Enable or disable the preamp.
Query the state of the preamp.
Select filter response (SLOW, MED or FAST).
Query the selected filter response.
OFF
MED
Table 3-8
OUTput command summary
Command Description
Default
Parameter SCPI
:OUTPut
:TTL[1]
:LSENse <name>
:LSENse?
:TTL2
:LSENse <name>
:LSENse?
:TTL3
:LSENse <name>
:LSENse?
:TTL4
:LSENse <name>
:LSENse?
Path to set polarity of digital output line 1:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 1.
Path to set polarity of digital output line 2:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 2.
Path to set polarity of digital output line 3:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 3.
Path to set polarity of digital output line 4:
Select polarity; active high (AHIGH) or active low (ALOW).
Query polarity of line 4.
(Note 1) (Note 2)
Notes:
1. None of the OUTPut subsystem commands are affected by *RST and :SYSTem:PRESet.
2. All OUTPut subsystem commands are non-SCPI.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
