Keithley 2002 User Manual

G
Example Programs
G-1
The following programs demonstrate various aspects of
Model 2002 operation. Most programs use only the Model
2002 while some include additional equipment, such as the
Model 2001-SCAN Scanner Card or a Model 7001 (or 7002)
Switch System.
The programs are written in Microsoft QuickBASIC 4.5 or
Microsoft QuickC 2.0. Most examples use the Keithley
(CEC) IEEE-488 interface cards. Other interfaces used
include IOtech and National GPIB.

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
